FD FG Anti-Vibration Damper

ʻO ka wehewehe pōkole:


Huahana Huahana

Huahana Huahana

wehewehe:

Hoʻohana ka damper anti-vibration preformed i ka uea preformed e like me ke ʻano o ka hoʻopili ʻana o ka pale kuʻekuʻe anti-vibration a me ka uea i pale ʻia, no laila ua loaʻa iā ia kahi mea metala preformed i maʻalahi a wikiwiki hoʻi e hoʻokomo a loaʻa ka ikaika eli maikaʻi ma ka uea (e pale i ka ʻO ka hoʻonui ʻana i ka wela a me ka hoʻopaʻa ʻana) ʻaʻole e hōʻeha i ka ʻeli ʻana i ka uea, ʻaʻohe pilikia huna o ka hemo ʻana o ka bolt (maintenance-free), anti-halo maikaʻi, mālama i ka ikehu (ua hana ʻia ka uea i hoʻopaʻa mua ʻia a me ka hoʻopili ʻana i ka alumini. alloy), ke kū'ē i ka luhi a me nā pono ʻē aʻe.

Nā hiʻohiʻona:

1.Pre-stranded uea no ka aluminika aahu kila kila

2.Easy hoʻouka (ʻaʻohe mea paahana e pono ai)

3.Safe a hilinaʻi (ʻaʻohe pōʻino i nā uea)

4. Maintenance-noa (ʻaʻohe bolts hemo)

5. ʻO nā kumukūʻai hoʻokomo haʻahaʻa (he ʻumi kekona wale nō e hoʻokomo i kahi huahana)

6.Easy a hilinaʻi ka ʻae a me ka nānā ʻana

Ka hoʻohālikelike ʻana o ka damper anti-vibration mua a me ka damper anti-vibration bolted kuʻuna:

Hoʻopaʻa ʻia nā pahu anti-vibration kuʻuna e nā bolts.I ka wā o ka hoʻokomo ʻana, pono e hoʻolako ʻia nā limahana hana me nā wrenches torque.Ke loaʻa ʻole kēia mau mea hana i ka hui kūkulu hale, hiki mai ka torque nui a liʻiliʻi paha.Hiki ke hoʻopōʻino i nā uwea a i ʻole nā ​​bolts i ka nui o ka torque;inā liʻiliʻi ka torque, ʻaʻole hiki i ka ʻeli ʻana ma waena o ka damper anti-vibration a me nā uea ke hoʻokō i ka maʻamau.

Hoʻopau ka damper anti-vibration preformed i nā hemahema o ka damper anti-vibration bolted i hōʻike ʻia ma luna.Hiki ke hoʻopau ʻia ka hoʻokomo ʻana o ka anti-vibration damper preformed me nā lima ʻole me ka pono ʻole o kahi mea hana hana, maʻalahi a wikiwiki hoʻi ka hoʻokomo ʻana, a haʻahaʻa ke kumukūʻai kūkulu.

ʻO ka paʻa ma waena o ka uea preformed a me ke alakaʻi o ka anti-vibration damper ua puʻunaue like ʻia ma luna o ka lōʻihi o 30 a 60 mm, ka mea e pale ai i ke koʻikoʻi o ka uea.

Eia kekahi, hiki ke nānā ʻia a hoʻokolokolo ʻia ka maikaʻi o ka hoʻonohonoho ʻana o ka preformed anti-vibration damper ma ka ʻāina me kahi telescope, e hōʻemi nui ana i ka paʻakikī a me ke kumukūʻai o ka ʻae ʻana i ka papahana a hoʻomaikaʻi nui i ka hilinaʻi o ka ʻae.

I ka hōʻuluʻulu ʻana, hiki ke hōʻuluʻulu ʻia nā pono o ka damper anti-vibration preformed penei:

1. Hoʻokomo maʻalahi a me ke kumu kūʻai haʻahaʻa;

2. Palekana a hilinaʻi, mālama ʻole;

3. ʻO ke kūlana kiʻekiʻe o ke kūkulu ʻana, kūpono a hilinaʻi.

Fsefs

ʻAno

Mahele ʻāpana uea i pili
(mm2)

Kiʻi

Anana
(mm)

Uea Uea

Kaumaha
(kg)

Uea Paʻa kila

ACSR AAC

D

A

H

L1

L

FD-1

/

35~50

IMG 2

40

40

40

95

300

7/2.6

1.5

FD-2

/

70~95

IMG 1

46

45

55

130

370

7/3.0

2.4

FD-3

/

120~150

IMG 1

56

60

65

150

450

19/2.2

4.5

FD-4

/

185~240

IMG 1

62

60

70

175

500

19/2.2

5.6

FD-5

/

300~500

IMG 1

67

70

70

200

550

19/2.6

7.2

FD-6

/

500~630

IMG 1

70

70

75

200

550

19/2.6

8.6

FG-35

35

/

IMG 2

42

45

50

100

300

7/3.0

1.8

FG-50

50

/

IMG 2

46

45

50

130

350

7/3.0

2.4

FG-70

70

/

IMG 1

56

50

60

150

400

19/2.2

4.2

FG-100

100

/

IMG 1

62

60

65

175

500

19/2.2

5.9

1. ʻO ke poʻo hāmare he hao hina a me ka lacquering, a ʻo ke koena he kila galvanized wela.Hoʻopili ʻia ke poʻo hāmare a me ke kaula kila e ka riveting.
2. E hoʻohui i ka huaʻōlelo Z ma hope o ka helu kumu hoʻohālike e hōʻike i ka hāmare hoʻolei piha ʻana, ʻo ia hoʻi, ua hoʻopili ʻia ke poʻo hāmare a me ke kaula kila ma ke ʻano hoʻoheheʻe hoʻohui.
